JX-8 European Standard Industrial Aluminium Profiles

Fortewin JX-8 industrial aluminium profiles are precision extruded from 6063-T5 alloy for machine frames, workstations, guards, automation equipment and modular structures. Standard length is 6 m, with custom cutting, machining and surface finishing available.

Page 19 catalogue specifications:

• JX-8-5050VS: 1.5 mm wall, 2.25 kg/m
• JX-8-50100V: 3.0 mm wall, 5.55 kg/m
• JX-8-60120V: 2.0 mm wall, 4.75 kg/m
• JX-8-6630V: 2.0 mm wall, 2.40 kg/m
• JX-8-50240V: 2.0 mm wall, 7.40 kg/m
• JX-8-6630VR: 2.0 mm wall, 2.30 kg/m
• JX-8-8080VA: approx. 2.0 mm wall, 3.80 kg/m
• JX-8-8080VB: 2.2 mm wall, 4.75 kg/m
• JX-8-8080VC: 4.0 mm wall, 5.40 kg/m
• JX-8-6060VS: 2.0 mm wall, 2.57 kg/m
• JX-8-6090V: 2.3 mm wall, 3.65 kg/m
• JX-8-8080VD: 5.0 mm wall, 7.00 kg/m
• JX-8-8080VAZ: 2.0 mm wall, 4.20 kg/m

Profiles are supplied in silver mill finish or can be anodized, powder coated and fabricated to drawing. Contact Fortewin with section, quantity and cutting requirements for a quotation. T/T payment is accepted: 60% advance after order confirmation and 40% balance before shipment.

6063-T5 aluminium profiles for machine frames

Select a JX-8 section by its drawing, mass per metre and wall thickness. For equipment frames, workstations and automation structures, confirm span, loading and connection details with your designer before ordering.

Frequently asked questions

Can JX-8 profiles be cut and machined to size?

Yes. Send your drawing, cut lengths, hole positions, critical tolerances and quantities for a feasibility review. Cutting, drilling, CNC machining and surface finishing can be assessed for your application.

Will these profiles fit my existing T-slot connectors?

Compatibility must be checked against the profile and connector drawings. The European-standard series name alone does not establish interchangeability with another supplier or brand.

What should I include in a quotation request?

Provide the JX-8 section code or drawing, alloy and temper, finish, cut lengths, quantity and delivery destination. Minimum order quantity, tooling and lead time are confirmed for each enquiry.

For modular guarding applications, see our equipment frame protective covers. Review the custom aluminium extrusion RFQ checklist before sending your specification.

Contact Mr. Luo at fortewinpvtltd@gmail.com or WhatsApp +86 18192440053.
